塑料 · PLASTIC

亚克力(PMMA)

ACRYLIC

亚克力，化学名称为聚甲基丙烯酸甲酯（PMMA），是一种高透明度的热塑性塑料。其透光率高达92%，优于普通玻璃，且具有良好的耐候性、可加工性和美学表现力。

Acrylic (PMMA) is a highly transparent thermoplastic with 92% light transmission, superior to ordinary glass.

§01
Plates

材料图版

§02
Characteristics

材料特性

透明度Transparency
高达92%，媲美玻璃甚至更纯净透明Up to 92%, comparable to glass or even more transparent
重量轻Light Weight
密度为1.18g/cm³，仅为玻璃的一半Density 1.18g/cm³, half that of glass
抗冲击性Impact Resistance
是普通玻璃的7~10倍，不易破裂7-10 times stronger than ordinary glass, not easily broken
可塑性强High Plasticity
可热弯、激光切割、CNC加工、抛光等Can be heat bent, laser cut, CNC machined, polished, etc.
色彩丰富Rich Colors
可生产透明、半透、乳白、荧光、染色等多种类型Available in transparent, semi-transparent, milky white, fluorescent, dyed and other types
表面表现Surface Finish
可实现镜面、哑光、纹理、磨砂、雕刻、打孔等效果Can achieve mirror, matte, textured, frosted, engraved, perforated effects
耐候性强Weather Resistance
室外使用不易黄变、老化，可用于灯箱与户外标识Resistant to yellowing and aging outdoors, suitable for light boxes and outdoor signage
电绝缘性优Electrical Insulation
适合用作绝缘外壳，且无磁性Suitable for insulating housings and non-magnetic
§03
Specifications

技术参数

属性 / Property数值 / Value单位 / Unit
密度Density1.181.18g/cm³
透光率Light Transmission9292%（透明型）%(transparent type)
熔点Melting Point约160~160°C
热变形温度Heat Deformation Temperature100–110100–110°C（可热弯）°C (bendable)
抗拉强度Tensile Strength60–7060–70MPa
§04
Manufacturing Process

制造工艺

成型方式

Forming Methods

挤压板（Extruded）：尺寸精度高，适合批量加工 浇铸板（Cast）：表面光滑、硬度高，适合雕刻、染色 注塑件：适合制作复杂三维形态，如灯罩、结构件

Extruded: High dimensional accuracy, suitable for batch processing Cast: Smooth surface, high hardness, suitable for engraving and dyeing Injection molded: Suitable for complex 3D shapes like lampshades and structural parts

加工方式

Processing Methods

激光切割 / CNC数控铣削 热弯成型 / 模具成型 表面处理（抛光、喷砂、雕刻、丝印、UV印刷） 粘接拼合（用专用亚克力胶）

Laser cutting / CNC milling Heat bending / Mold forming Surface treatment (polishing, sandblasting, engraving, screen printing, UV printing) Adhesive assembly (with special acrylic adhesive)

§05
Applications

应用场景

  • App. 01

    展示设计

    Display Design

    橱窗道具、展览模型、陈列架、展板、导视系统

    Window displays, exhibition models, display racks, panels, signage systems

  • App. 02

    光影装置

    Lighting Installation

    亚克力导光板、灯罩、背光字体、感应面板

    Acrylic light guide plates, lampshades, backlit fonts, sensor panels

  • App. 03

    产品外壳

    Product Housing

    化妆品包装、高端文具、耳机支架、电子产品壳体

    Cosmetic packaging, high-end stationery, headphone stands, electronic product housings

  • App. 04

    室内装饰

    Interior Decoration

    亚克力隔断、镜面墙面、柜体饰面、嵌灯罩板

    Acrylic partitions, mirror walls, cabinet finishes, embedded lamp covers

  • App. 05

    公共艺术

    Public Art

    雕塑壳体、镜面互动墙、激光切割图形、互动光阵列结构

    Sculpture shells, mirror interactive walls, laser-cut graphics, interactive light array structures
